PH7-5006 LẮP RÁP LOẠI RJ45 VỚI KIM LOẠI BÌA PATCH CORD
Mô tả ngắn:
CAT5E UTP4 Patch cord : Standard CAT5E UTP4 or CAR6 UTP4 26 AWG; 24 AWG strand copper or CCA material Different PVC color available Cable length: 1M; 1.5M; 1.8M; 3M ;5M ;10M PACKING: gift polybag each one Transmission Performance Frequency (MHz) NEXT (2M) dB(Min) NEXT (5M) dB(Min) NEXT (10M) dB(Min) Return Loss dB(Min) 10 54.5 53.7 52.8 22.8 20 48.6 47.9 47.1 23.7 25 46.7 46.0 45.3 24.0 31.25 44.8 44.2 43.6 23.0 62.5 39.0 38.5 38.1 20.0 100 35.1 34.8 34.6 18.0 (All dates abo...
Chi tiết sản phẩm
Tags cho sản phẩm
CAT5E UTP4 Patch cord :
Standard CAT5E UTP4 or CAR6 UTP4
26 AWG; 24 AWG strand copper or CCA material
Different PVC color available
Cable length: 1M; 1.5M; 1.8M; 3M ;5M ;10M
PACKING: gift polybag each one
Transmission Performance
| Frequency (MHz) |
NEXT (2M) dB(Min) |
NEXT (5M) dB(Min) |
NEXT (10M) dB(Min) |
Return Loss dB(Min) |
| 10 | 54.5 | 53.7 | 52.8 | 22.8 |
| 20 | 48.6 | 47.9 | 47.1 | 23.7 |
| 25 | 46.7 | 46.0 | 45.3 | 24.0 |
| 31.25 | 44.8 | 44.2 | 43.6 | 23.0 |
| 62.5 | 39.0 | 38.5 | 38.1 | 20.0 |
| 100 | 35.1 | 34.8 | 34.6 | 18.0 |
(All dates above are lab testing results, the actual testing results are not the same as these dates,
based on the actual testing results.)
